Optical Sorters for Better Material Separation
Fully separate your material and get the maximum value for each fraction.
Increase Recovery Rates
Separate copper and other metals precisely and accurately.
Raise Purity Levels
Ensure the highest quality of each individual metal stream.
Become More Versatile
Process and isolate more materials with greater throughput.
Optical Sorters Designed For Recycling
Chromasort’s optical sorters integrate seamlessly into your processing line. We provide training and instruction on how to handle each different material you will be recycling and help with adjustments on how to sort them based on your requirements. Our optical sorters make market-saleable products.
Sort Out Brass
Divide out and keep your red metals separate.
Separate Zinc
Eliminate white metal contamination from your copper.
Isolate Die Cast
Remove low value non-ferrous from your high value non-ferrous.
Pick Your Optical Sorter in 3 Simple Steps
Determine if an optical sorter is right for your operation and get your recycling business to the next level.
Fill Out Our Request a Quote Form
Tell us about the materials you plan to process, your volumes, and other needs you are looking for in your copper recycling line.
Evaluate Your Options With an Expert
One of our professionals will reach out to you and conduct a thorough assessment, reviewing all potential solutions with you.
Choose the Right Fit for You
We will educate you on an optical sorter option so you are empowered to make the best decision for your business.
Make More Money From Your Processing Line
Getting the full value of your materials does not need to be so difficult. Our team is here to provide you with an individualized optical sorter solution for your current and future plans. We are focused on getting you the right system and options for your specific process. Get in touch and see how you can benefit from our optical sorters!
Contact Us For More Information
📱 (860) 670-1890
📧 info@chromasort.com
Frequently Asked Questions (FAQ)
It works by cameras and air nozzles. If the human eye can detect a difference in material, for any reason, the Chromasort can be trained to do the same.
It can separate almost anything that is optically distinct but a short list is: copper, aluminum, electronic scrap, green boards, tinned copper, stainless steel, insulated copper wire (ICW), colored plastic, auto shredder residue (ASR), auto shredder residue wire (ASRW), brass, and more.
The Chromasort can effectively handle materials ranging from 1mm to 60mm in size.
The throughput is about 1 to 2 tons/hour but is affected by the percentage of contaminants and feedstock size. For example, the higher the contaminants and/or the smaller the feedstock, the less throughput.
We can send the machine already programmed to your material(s) if you send us samples prior to shipment. We also can program it on-site. Or we can train you remotely, if you choose.
The Chromasort needs 480V, 3-phase, and 85 CFM of air to run.
Maintenance includes a weekly valve check which is done by the machine, monthly air filter replacements, and general housekeeping by making sure the optical sorter is clean.
Support is done through remoting into the machine or an on-site technician.
Yes, you can send us samples to test the Chromasort’s effectiveness. Please email info@chromasort.com to get the process started.
Purchasing a Chromasort optical sorter includes (1) pan feeder, (1) AI optical sorter, (2) underbelly conveyors, and (2) exit conveyors.
As of May 2026, the lead time for a Chromasort is 90 days.
